Name |
SHACMAN YARD TRUCK |
|
Drive Type |
4x2 |
|
Engine |
WEICHAI WP7.240E30, 240HP, EORO III |
|
Gearbox |
Allison 3500P with PTO, F5&R1, Automatic Hydraulic propulsion, with interlock function |
|
Front Axle |
MAN 7.5T |
|
Rear Axle |
STR 16t, Double reduction drive axle/ Ratio 11.98 |
|
Steering |
Hydraulic power steering |
|
Cabin |
Unilateral offset cab, Left door, the sliding door at back, Left & right sliding window, roof-top A/C condition, Heater; Bumper thickness 8mm steel, Width 2500mm,Distance to Cab front is 200mm. |
|
Fuel Tank |
200L Aluminum +Protected by guard |
|
The Fifthwheel |
Lifting fifth wheel;Type: 3.5’’; Max height from ground≥1500MM |
|
Kerb Weight |
8000kg |
|
GCW |
60000kg |
|
Min. Turning Radius |
6200mm |
|
Wheelbase |
3200mm |
|
Overall Dimension |
5475x2500x3160mm |
